600 amp Robotic Water-Cooled MIG Guns

The Tregaskiss® 600 amp robotic water-cooled MIG gun is ready to take on your most demanding welding applications. Its rugged design is tough and dependable enough to maximize productivity when welding thick plate or running prolonged duty cycles.

In addition to having a water-cooled power cable, the neck features four cooling channels that provide significant water-cooling capacity to the front-end components, keeping them cool and extending their usable life.

The stainless steel docking body is built to last and will not deteriorate during the serviceable life of this robotic water-cooled MIG gun. Plus, the heavy-duty monocoil cable provides a rigid support for the liner, resulting in smooth and consistent wire feeding. In the event that a component has to be adjusted or replaced, this MIG gun is entirely serviceable and easy to repair.

more...

Configure My Gun Reverse Lookup

Rugged Construction

  • Durable stainless steel docking body
  • Durable conduit swivels independently and provides rigid support for the liner, resulting in smooth and consistent wire feeding
  • Maintenance-friendly features include accessible front housing, quick-change fittings and replaceable components

Reliable Performance

  • Withstands heat from welding thick plate or prolonged duty cycles
  • Water-cooled neck and power cable keep front-end consumables cool
  • Neck features four cooling channels

Processes

  • MIG (GMAW) welding

Duty Cycle Rating

  • 60%: 600 amp with mixed gases
  • Ratings are based on tests that comply with IEC 60974-7 standards

Customize your Tregaskiss® 600 amp robotic water-cooled MIG gun online

Configure an entire system or just the gun part number you need, or reverse lookup your existing gun part number – plus get access to additional resources and an expanded replacement parts list with diagram.

This new mobile-friendly online configurator provides downloadable exploded view diagrams and other valuable takeaways that you can print, save in PDF format for later, or share via email.

Check it out today!

Please note that the following additional components are required when configuring a complete robotic system and are sold separately:

Configure a Tregaskiss 600 amp robotic water-cooled MIG gun online
Find the replacement parts list and other details for the Tregaskiss 600 amp robotic water-cooled MIG gun you already have

Part Numbers


Heavy Duty; Copper

Part NumberDescription
T-A030CH*^for 0.030″ (0.8 mm) wire; qty. 10
T-A035CH*^for 0.035″ (0.9 mm) wire; qty. 10
T-A039CH*^for 0.039″ (1.0 mm) wire; qty. 10
T-A045CH*^for 0.045″ (1.2 mm) wire; qty. 10
T-A052CH*^for 0.052″ (1.3 mm) wire; qty. 10
T-A062CH*for 1/16″ (1.6 mm) wire; qty. 10
T-A072CH*for 0.072″ (1.8 mm) wire; qty. 10
T-A078CH*for 5/64″ (2.0 mm) wire; qty. 10
T-A094CH*for 3/32″ (2.4 mm) wire; qty. 10

*add “-100 to end of the above part numbers for quantities of 100.
^add “-1000” to end of the above part numbers for quantities of 1000.

Heavy Duty; Chrome Zirconium

Part NumberDescription
T-A030ZH*for 0.030″ (0.8 mm) wire; qty. 10
T-A035ZH*for 0.035″ (0.9 mm) wire; qty. 10
T-A039ZH*for 0.039″ (1.0 mm) wire; qty. 10
T-A045ZH*for 0.045″ (1.2 mm) wire; qty. 10
T-A052ZH*for 0.052″ (1.3 mm) wire; qty. 10
T-A062ZH*for 1/16″ (1.6 mm) wire; qty. 10

*add “-100 to end of the above part numbers for quantities of 100.

Part NumberDescription
D-ATTH-RW1Diffuser, thread-on; qty. 25
Part NumberDescription
671-6-75Water-cooled nozzle; 3/4″ bore, 1/8″ recess, 1″ O.D.; qty. 10
671-8-75Water-cooled nozzle; 3/4″ bore, 1/8″ stick out, 1″ O.D.; qty. 10

Heavy Duty; Copper

Part NumberDescription
403-20-30for 0.030″ (0.8 mm) wire
403-20-35for 0.035″ (0.9 mm) wire
403-20-1.0for 0.040″ (1.0 mm) wire
403-20-45for 0.045″ (1.2 mm) wire
403-20-364for 3/64″ (1.2 mm) wire
403-20-52for 0.052″ (1.3 mm) wire
403-20-1.4for 0.055″ (1.4 mm) wire
403-20-116for 1/16″ (1.6 mm) wire
403-20-1.8for 0.070″ (1.8 mm) wire
403-20-78for 0.078″ (2.0 mm) wire
403-20-564for 5/64″ (2.0 mm) wire
403-20-332for 3/32″ (2.4 mm) wire

Heavy Duty; Chrome Zirconium

Part NumberDescription
403-27-30for 0.030″ (0.8 mm) wire
403-27-35for 0.035″ (0.9 mm) wire
403-27-1.0for 0.040″ (1.0 mm) wire
403-27-45for 0.045″ (1.2 mm) wire
403-27-364for 3/64″ (1.2 mm) wire
Part NumberDescription
404-71Diffuser, water-cooled, thread-on
Part NumberDescription
671-6-75Water-cooled nozzle; 3/4″ bore, 1/8″ recess, 1″ O.D.
671-8-75Water-cooled nozzle; 3/4″ bore, 1/8″ stick out, 1″ O.D.
Part NumberDescription
415-35-6for 0.035″ (0.9 mm) – 0.045″ (1.2 mm) wire; 6 ft (1.8 m)
415-35-10for 0.035″ (0.9 mm) – 0.045″ (1.2 mm) wire; 10 ft (3.05 m)
415-35-15for 0.035″ (0.9 mm) – 0.045″ (1.2 mm) wire; 15 ft (5.0 m)
415-116-6Wfor 0.045″ (1.2 mm) – 1/16″ (1.6 mm) wire; 6 ft (1.8 m)
415-116-10Wfor 0.045″ (1.2 mm) – 1/16″ (1.6 mm) wire; 10 ft (3.05 m)
415-116-15Wfor 0.045″ (1.2 mm) – 1/16″ (1.6 mm) wire; 15 ft (5.0 m)
415-564-6Wfor 1/16″ (1.6 mm) – 5/64″ (2.0 mm) wire; 6 ft (1.8 m)
415-564-10Wfor 1/16″ (1.6 mm) – 5/64″ (2.0 mm) wire; 10 ft (3.05 m)
415-564-5Wfor 1/16″ (1.6 mm) – 5/64″ (2.0 mm) wire; 15 ft (5.0 m)
Part NumberDescription
495-19-35for 0.035″ (0.9 mm) – 0.045″ (1.2 mm) wire; 26″
495-19-116for 0.045″ (1.2 mm) – 1/16″ (1.6 mm) wire; 26″
Power Through Spatter with the NEW TOUGH GUN TT4A and TT4E Reamer Nozzle Cleaning Stations

TOUGH GUN® TT4 Reamer

The TOUGH GUN TT4 reamer robotic nozzle cleaning station — now available in both analog and Ethernet models — is TOUGH on spatter and operates reliably in even the harshest welding environments. Automating spatter removal will help to extend the life of your robotic MIG guns and consumables, benefiting both your bottom line and your production uptime and throughput. Learn more about the TOUGH GUN TT4A reamer or the TOUGH GUN TT4E reamer.


TOUGH GUN TT4 Reamer on a TOUGH GUN Multi-Feed System

TOUGH GARD® Anti-Spatter Multi-Feed System

Interested in the ultimate solution to refilling the reservoirs on your nozzle cleaning stations? Feed up to 10 TOUGH GUN Reamer units from a single 5-gallon or 55-gallon drum of TOUGH GARD anti-spatter liquid with the TOUGH GARD multi-feed system. Find out more.


New 2021 TOUGH GARD anti-spatter liquid product family

TOUGH GARD Anti-Spatter Liquid

This ready-to-use water-soluble, non-toxic product creates a sacrificial surface that reduces spatter adhesion and won’t clog the sprayer like oil-based anti-spatter solutions. This prolongs the life of your consumables and minimizes downtime due to nozzle cleaning, which can help reduce your operating and maintenance costs. Learn more.


Neck Checking Fixture

The TOUGH GUN neck checking fixture allows you to verify and re-master your tool center point (TCP). In the event of a collision, this fixture can be used to realign the neck on your robotic MIG welding gun.

Robotic water-cooled neck checking fixture part numbers:

Part NumberDescription
RW1-3200-22Gfor 22 degree necks
RW1-3200-45Gfor 45 degree necks
